Benefiting from its built-in 10GbE SFP+ LAN ports, the quad-core Synology NAS offers SMBs ultra-fast performance required for the rigorous data processing and virtualization tasks that our future demands.
Powered by an all-new quad-core CPU and a RAM module expandable to 8GB (coming with 4GB by default), DS2015xs delivers over 1635.12 MB/s throughput.1The extraordinary performance far outshines other NAS servers in its price range, and allows DS2015xs to deal with considerable amount of data processing requests from business’ critical services.
| Hardware Specifications | |
| CPU | |
| CPU Model | Annapurna Labs Alpine AL-514 |
| CPU Architecture | 32-bit |
| CPU Frequency | Quad Core 1.7 GHz |
| Floating Point | |
| Hardware Encryption Engine | |
| Memory | |
| System Memory | 4 GB DDR3 |
| Memory Module Pre-installed | 4 GB x 1 |
| Total Memory Slots | 2 |
| Memory Expandable up to | 8 GB (4 GB X 2) |
| Storage | |
| Drive Bay(s) | 8 |
| Maximum Drive Bays with Expansion Unit | 20 |
| Compatible Drive Type |
|
| Maximum Internal Raw Capacity | 64 TB (8 TB HDD x 8) (Capacity may vary by RAID types) |
| Maximum Raw Capacity with Expansion Units | 160 TB (8 TB HDD x 20) (Capacity may vary by RAID types) |
| Maximum Single Volume Size | 108 TB |
| Hot Swappable Drive | |
| External Ports | |
| USB 3.0 Port | 2 |
| Expansion Port | 1 |
| File System | |
| Internal Drives | EXT4 |
| External Drives |
|
| Appearance | |
| Size (Height x Width x Depth) | 157 mm x 340 mm x 233 mm |
| Weight | 5.21 kg |
| Others | |
| RJ-45 1GbE LAN Port | 2 (with Link Aggregation / Failover support) |
| Wake on LAN/WAN | |
| SFP+ 10GbE LAN Port* | 2 (with Link Aggregation / Failover support) |
| System Fan | 120 mm x 120 mm x 2 pcs |
| Fan Speed Mode |
|
| Easy Replacement System Fan | |
| Wireless Support (dongle) | |
| Power Recovery | |
| Noise Level* | 24.1 dB(A) |
| Scheduled Power On/Off | |
| Power Supply Unit / Adapter | 250W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 47.44 W (Access) 22.98 W (HDD Hibernation) |
| British Thermal Unit | 161.87 BTU/hr (Access) 78.41 BTU/hr (HDD Hibernation) |
| Environment Temperature | |
| Operating Temperature | 5°C to 35°C (40°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification |
|
| Warranty | 5 Years |
| Notes |
|
| DSM Specifications | |
| Storage Management | |
| Maximum Internal Volume Number | 1024 |
| Maximum iSCSI Target Number | 64 |
| Maximum iSCSI LUN | 512 |
| iSCSI LUN Clone/Snapshot, Windows ODX | |
| Supported RAID Type |
|
| RAID Migration |
|
| Volume Expansion with Larger HDDs |
|
| Volume Expansion by Adding a HDD |
|
| Global Hot Spare Supported RAID Type |
|
| SSD Support | |
| SSD Read/Write Cache | |
| File Sharing Capacity | |
| Maximum User Accounts | 16000 |
| Maximum Groups | 512 |
| Maximum Shared Folder | 512 |
| Maximum Shared Folder Sync Tasks | 16 |
| Maximum Concurrent CIFS/AFP/FTP Connections | 1024 |
| Windows Access Control List (ACL) Integration | |
| NFS Kerberos Authentication | |
| High Availability Manager | |
| Log Center | |
| Syslog Events per Second | 3000 |
| Virtualization | |
| VMware vSphere 5 with VAAI | |
| Windows Server 2012 | |
| Windows Server 2012 R2 | |
| Citrix Ready | |
| Add-on Packages | |
| Central Management System | |
| Cloud Station Server | |
| Maximum Concurrent File Transfers | 1024 |
| Maximum Concurrent File Transfers (with RAM expansion) | 2000 |
| Download Station | |
| Maximum Concurrent Download Tasks | 80 |
| HiDrive Backup | |
| Media Server | |
| DLNA Compliance | |
| PDF Viewer | |
| SpreadSheet | |
| Maximum Simultaneous Editing Users | 90 |
| Surveillance Station | |
| Maximum IP cam (Licenses required) | 40 (including 2 Free License) |
| Total FPS (H.264)* | 1200 FPS @ 720p (1280×720) 600 FPS @ 1080p (1920×1080) 350 FPS @ 3M (2048×1536) 180 FPS @ 5M (2591×1944) |
| Total FPS (MJPEG)* | 450 FPS @ 720p (1280×720) 225 FPS @ 1080p (1920×1080) 150 FPS @ 3M (2048×1536) 100 FPS @ 5M (2591×1944) |
| Notes | Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera. |
| Video Station | |
| Video Transcoding | Group 1 – Type 2 |
| Maximum Transcoding Channel Number | 1 channel, 30 FPS @ 720p (1280×720), H.264 (AVC)/MPEG-4 Part 2 (XVID, DIVX5)/MPEG-2/VC-1 |
| VPN Server | |
| Maximum Connections | 20 |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content |
|
| Optional Accessories |
|
