Optimized for multimedia processing, DS415play features 1080p Full HD video transcoding, delivering on-demand Full HD transcoding to guarantee seamless streaming experiences.
Powered by a hardware accelerated transcoding engine, DS415play features 1080p Full HD video transcoding on the fly, effortlessly sharing videos with your smart TV, network media player, mobile devices, and PC. DS415play also supports multi-channel streaming, letting family members enjoy movies in different rooms.
| Hardware Specifications | |
| CPU | |
| CPU Model | Intel Atom CE5335 |
| CPU Architecture | 32-bit |
| CPU Frequency | Dual Core 1.6 GHz |
| Floating Point | |
| Hardware Transcoding Engine | H.264 (AVC), MPEG-4 Part 2, MPEG-2, VC-1 |
| Memory | |
| System Memory | 1 GB DDR3 |
| Storage | |
| Drive Bay(s) | 4 |
| Compatible Drive Type |
|
| Maximum Internal Raw Capacity | 32 TB (8 TB HDD x 4) (Capacity may vary by RAID types) |
| Maximum Single Volume Size | 16 TB |
| Hot Swappable Drive | |
| External Ports | |
| USB 2.0 Port | 3 |
| USB 3.0 Port | 2 |
| File System | |
| Internal Drives | EXT4 |
| External Drives |
|
| Appearance | |
| Size (Height x Width x Depth) | 165 mm x 203 mm x 233.2 mm |
| Weight | 2.03 kg |
| Others | |
| RJ-45 1GbE LAN Port | 1 |
| Wake on LAN/WAN | |
| System Fan | 92 mm x 92 mm x 2 pcs |
| Fan Speed Mode |
|
| Wireless Support (dongle) | |
| Power Recovery | |
| Noise Level* | 20.0 dB(A) |
| Scheduled Power On/Off | |
| Power Supply Unit / Adapter | 90W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 27.33 W (Access) 16.84 W (HDD Hibernation) |
| British Thermal Unit | 93.25 BTU/hr (Access) 57.46 BTU/hr (HDD Hibernation) |
| Environment Temperature | |
| Operating Temperature | 5°C to 35°C (40°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification |
|
| Warranty | 2 Years |
| Notes |
|
| DSM Specifications | |
| Storage Management | |
| Maximum Internal Volume Number | 256 |
| Maximum iSCSI Target Number | 10 |
| Maximum iSCSI LUN | 10 |
| Supported RAID Type |
|
| RAID Migration |
|
| Volume Expansion with Larger HDDs |
|
| Volume Expansion by Adding a HDD |
|
| Global Hot Spare Supported RAID Type |
|
| File Sharing Capacity | |
| Maximum User Accounts | 2048 |
| Maximum Groups | 256 |
| Maximum Shared Folder | 256 |
| Maximum Shared Folder Sync Tasks | 4 |
| Maximum Concurrent CIFS/AFP/FTP Connections | 256 |
| Windows Access Control List (ACL) Integration | |
| NFS Kerberos Authentication | |
| Log Center | |
| Syslog Events per Second | 400 |
| Add-on Packages | |
| Antivirus by McAfee (Trial) | |
| Cloud Station Server | |
| Maximum Concurrent File Transfers | 256 |
| Download Station | |
| Maximum Concurrent Download Tasks | 50 |
| HiDrive Backup | |
| Media Server | |
| DLNA Certification | |
| PDF Viewer | |
| SpreadSheet | |
| Maximum Simultaneous Editing Users | 70 |
| Surveillance Station | |
| Maximum IP cam (Licenses required) | 15 (including 2 Free License) |
| Total FPS (H.264)* | 450 FPS @ 720p (1280×720) 150 FPS @ 1080p (1920×1080) 100 FPS @ 3M (2048×1536) 80 FPS @ 5M (2591×1944) |
| Total FPS (MJPEG)* | 210 FPS @ 720p (1280×720) 50 FPS @ 1080p (1920×1080) 40 FPS @ 3M (2048×1536) 30 FPS @ 5M (2591×1944) |
| Notes | Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera. |
| Video Station | |
| Video Transcoding | Group 1 – Type 1 |
| Maximum Transcoding Channel Number | 1 channel, 30 FPS @ 1080p(1920×1080), H.264 (AVC)/MPEG-4 Part 2 (XVID, DIVX5)/MPEG-2/VC-1 |
| VPN Server | |
| Maximum Connections | 15 |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content |
|
| Optional Accessories |
|
