DiskStation DS115j
OverView
Compact, lightweight, and energy-efficient, DS115j is perfect for budget-conscious home users looking for a simple, yet feature-rich NAS server. Easily back up documents, monitor live surveillance feeds, or build a personal cloud to share files with friends and family.
Specifications
| Hardware Specifications | |
| CPU | |
| CPU Model | Marvell Armada 370 88F6707 |
| CPU Architecture | 32-bit |
| CPU Frequency | 800 MHz |
| Floating Point | |
| Hardware Encryption Engine | |
| Memory | |
| System Memory | 256 MB DDR3 |
| Storage | |
| Drive Bay(s) | 1 |
| Compatible Drive Type |
|
| Maximum Internal Raw Capacity | 8 TB (8 TB HDD x 1) (Capacity may vary by RAID types) |
| Maximum Single Volume Size | 16 TB |
| External Ports | |
| USB 2.0 Port | 2 |
| File System | |
| Internal Drives | EXT4 |
| External Drives |
|
| Appearance | |
| Size (Height x Width x Depth) | 166 mm x 71 mm x 224 mm |
| Weight | 0.71 kg |
| Others | |
| RJ-45 1GbE LAN Port | 1 |
| System Fan | 60 mm x 60 mm x 1 pcs |
| Fan Speed Mode |
|
| Wireless Support (dongle) | |
| Power Recovery | |
| Noise Level* | 18.1 dB(A) |
| Power Supply Unit / Adapter | 36W |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 10.52 W (Access) 4.97 W (HDD Hibernation) |
| British Thermal Unit | 35.90 BTU/hr (Access) 16.96 BTU/hr (HDD Hibernation) |
| Environment Temperature | |
| Operating Temperature | 5°C to 35°C (40°F to 95°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification |
|
| Warranty | 2 Years |
| Notes |
|
| DSM Specifications | |
| Storage Management | |
| Maximum Internal Volume Number | 1 |
| Maximum iSCSI Target Number | 10 |
| Maximum iSCSI LUN | 10 |
| Supported RAID Type | Basic |
| File Sharing Capacity | |
| Maximum User Accounts | 512 |
| Maximum Groups | 128 |
| Maximum Shared Folder | 256 |
| Maximum Shared Folder Sync Tasks | 2 |
| Maximum Concurrent CIFS/AFP/FTP Connections | 64 |
| Windows Access Control List (ACL) Integration | |
| NFS Kerberos Authentication | |
| Log Center | |
| Syslog Events per Second | 50 |
| Add-on Packages | |
| Cloud Station Server | |
| Maximum Concurrent File Transfers | 64 |
| Download Station | |
| Maximum Concurrent Download Tasks | 20 |
| HiDrive Backup | |
| Media Server | |
| DLNA Compliance | |
| PDF Viewer | |
| SpreadSheet | |
| Maximum Simultaneous Editing Users | 10 |
| Surveillance Station | |
| Maximum IP cam (Licenses required) | 5 (including 2 Free License) |
| Total FPS (H.264)* | 50 FPS @ 720p (1280×720) 20 FPS @ 1080p (1920×1080) 10 FPS @ 3M (2048×1536) 10 FPS @ 5M (2591×1944) |
| Total FPS (MJPEG)* | 20 FPS @ 720p (1280×720) 10 FPS @ 1080p (1920×1080) 10 FPS @ 3M (2048×1536) 6 FPS @ 5M (2591×1944) |
| Notes | Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera. |
| Video Station | |
| Video Transcoding | Group 2 |
| VPN Server | |
| Maximum Connections | 5 |
| Environment & Packaging | |
| Environment | RoHS Compliant |
| Packaging Content |
|
| Optional Accessories |
|
